Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
Model Number: RX-78TMERCB9
Product Name: AMD Radeon™ RX 7800 XT
Product Description: XFX SPEEDSTER MERC319 RADEON RX 7800 XT BLACK Gaming Graphics Card with 16GB GDDR6 HDMI 3xDP, AMD RDNA™ 3
Short Description : XFX SPEEDSTER MERC319 RADEON RX 7800 XT Black Edition
Launch Date: September 6, 2023
UPC Number: 840191502460
Bus Type: PCI-E 4.0
Primary Clock Speeds:
Base Clock Up To: 1624 MHz
Game Clock Up To: 2254 MHz
Boost Clock Up to: 2565 MHz
Stream Processors: 3840
Compute Units: 60
Memory Bus: 256bit
Memory Clock: 19.5 Gbps
Memory Size: 16 GB
Memory Bandwidth: Up to 624 GB/s
Effective Memory Bandwidth: Up to 2708 GB/s
Memory Type: GDDR6
Card Profile: 2.75 slot
Thermal Solution: 3 Fan w/ Vapor Chamber
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
DisplayPort 2.1: 3x
HDMI™ 2.1: 1x
External Power: 2x PCI-E 8 pin connections
Minimum Power Supply Requirement: 700 watt
Warranty card - QR Code Insert: 1x
Card Dimension (cm) 32.6 x12.6 x5.8
Card Dimension (inch) 12.83 x 4.96 x 2.28
Master Carton Dimensions (cm) 46 x 39.5 x 47.5
Master Carton Dimensions (inch) 18.11 x 15.55 x 18.7
Master Carton Weight (Kg) ~13.5
Master Carton Weight (lb) ~29.76
Package Dimensions (cm) 44.5 x 23.5 x 12.5
Package Dimensions (inch) 17.51 x 9.25 x 4.92
Package Weight (Kg) ~2
Package Weight (lb) ~1.41
60 AMD RDNA™ 3 Compute Units(with RT+AI Accelerators)
AMD Infinity Cache™ technology
AMD Radiance Display™ Engine
AMD Radeon™ Boost technology*
AMD Radeon™ Anti-Lag* technology*
16GB GDDR6 on 256-Bit Memory Bus
PCI® Express 4.0 ready
AMD FidelityFX™ technologies*
AMD FidelityFX™ Super Resolution technology*
Microsoft® DirectX® 12 Ultimate
AMD smart technologies*
AMD Software: Adrenalin Edition™ application
AMD Noise Suppression*
AMD Privacy View*
AMD Radeon™ Super Resolution technology*
AMD Freesync™ technology*
HDMI™ 4K Support
4K H264 Decode
4K H264 Encode
XFX fans are equipped to run at the highest possible performance, while our Zero DB Fan System will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
The Speedster series exemplifies a modern aerodynamic style through a clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
With each iteration of the XFX Merc series, we have simplified the design while improving performance. This newest iteration introduces our all-new ridged backplate design which increases the overall surface area by 33%, the results are increased in heat dissipation when paired with thermal pads.
Our new design features a straight-through airflow venting to significantly improve cooling and compliments the open design of the Ghost Thermal floating shroud design along with numerous other cooling features.
The XFX MERC 319 7800 XT uses a vapor chamber design, a more efficient method for heat dissipation than traditional cold plates alone. The vapor chamber can quickly quickly and efficiently transfer heat from the GPU and VRAM to the heat pipes, and then into the heatsink assembly.
We know enthusiast like options, so for the XFX MERC 319 7800 XT graphics cards, we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update or flash.
With a 14-phase power design, and a dedicated 9-phases for GPU GFX Core, the QICK 319 7800 XT provides you with stable gameplay and gives better power distribution across the VRMs. This allows the GPU to operate cooler at baseline but also has tremendous room to overclock thanks to XFX's increased power delivery BIOS.
The MERC 319 7800 XT GPUs utilize 13-blade structure fans that provide better endurance and efficiency over other designs. Reducing friction and heat these, fans operate quieter and have increased lifespan.
Breakthrough new levels of performance with 16GB of GDDR6 memory and blazing-fast clock speeds to deliver an incredible experience at 1440p and beyond. Radeon™ RX 7000 Series graphics feature advanced AMD RDNA™ 3 compute units, with 2nd generation raytracing accelerators and new AI accelerators to deliver incredible performance while maximizing graphical fidelity.
Featuring ultra-fast 2nd generation AMD Infinity Cache™ technology connected through an ultra-high bandwidth chiplet interconnect. • 28.1 billion Transistors
A pixel-perfect experience starts with Radeon™ RX 7800 XT Series graphics cards. Immerse yourself in your favorite visual vistas with stunning image clarity and up to 68 billion colors at up to 8K 165Hz. The Radeon™ RX 7800 XT Series delivers a jaw-dropping visual experience you need to see to believe.
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz. • DisplayPort™ 2.1 • 12-Bit HDR up to 68 billion Colors
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders4. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression5 featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
A revolutionary new memory level in AMD RDNA™ 3 architecture. 64 MB of AMD Infinity Cache enables high bandwidth performance of up to 2709 GB/s Effective Memory Bandwidth
Get more performance in select titles through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCIe® 4.0
With up to 60 enhanced compute units delivering powerhouse performance, even 8K gaming is now possible at smooth framerates thanks to FSR.
Equipped with 16GB of advanced GDDR6 memory with a 256-bit interface , enabling 1440p performance in today’s most demanding games.
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput of 16 GT/s which enables two times the bandwidth compared to PCIe® 3.0.
AMD Power most of todays newest consoles but also more Gaming PCs and Consoles are powered by AMD*. It's obvious what is the real choice when it comes to high performance graphics at a great value.
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
